Steel single bread wall
- Details
Wall structure: all steel system
Wall appearance: wall thickness 50mm, baseboard height 40mm, module spacing 6mm.
Glass assembly: safety or fireproof glass with a thickness of 5 or 6 mm
Fire endurance: EI120min
Impact strength: 1000Nm
Sound insulation load: 48dB-50dB
Panel assembly: The system is equipped with 16mm thick steel composite panel (1.0mm steel plate lining 15mm gypsum board). It can also be used with any veneer of 12 or 15mm thickness, or with 5 or 6mm thick safety or fireproof glass.
Note: Steel panels are between 300-952mm wide and the height is not limited, just consider shipping and loading. The surface of the panel can be treated with solid color or wood grain color, and the color and texture are rich and varied.
Wall appearance: wall thickness 50mm, baseboard height 40mm, module spacing 6mm.
Glass assembly: safety or fireproof glass with a thickness of 5 or 6 mm
Fire endurance: EI120min
Impact strength: 1000Nm
Sound insulation load: 48dB-50dB
Panel assembly: The system is equipped with 16mm thick steel composite panel (1.0mm steel plate lining 15mm gypsum board). It can also be used with any veneer of 12 or 15mm thickness, or with 5 or 6mm thick safety or fireproof glass.
Note: Steel panels are between 300-952mm wide and the height is not limited, just consider shipping and loading. The surface of the panel can be treated with solid color or wood grain color, and the color and texture are rich and varied.
