Steel panel
- Details
Wall structure: all steel system
Wall appearance: wall thickness 100mm, upper and lower rail height 40mm, module spacing 6mm.
Fire endurance: EI120min
Impact strength: 550Nm
Sound insulation load: 42dB-50dB
Panel assembly: It adopts 0.8mm environmental protection galvanized steel plate or stainless steel plate for rolling forming, surface spraying or sanding treatment, lining 15mm gypsum board; panel fastener integrated design.
Note: The steel panel has a width of 300-1150mm and the height is not limited. Just consider transportation and loading. The surface of the panel can be treated with solid color or wood grain color, and the color and texture are rich and varied.
Wall appearance: wall thickness 100mm, upper and lower rail height 40mm, module spacing 6mm.
Fire endurance: EI120min
Impact strength: 550Nm
Sound insulation load: 42dB-50dB
Panel assembly: It adopts 0.8mm environmental protection galvanized steel plate or stainless steel plate for rolling forming, surface spraying or sanding treatment, lining 15mm gypsum board; panel fastener integrated design.
Note: The steel panel has a width of 300-1150mm and the height is not limited. Just consider transportation and loading. The surface of the panel can be treated with solid color or wood grain color, and the color and texture are rich and varied.
