Wall structure: all aluminum system
Wall appearance: wall thickness 100mm, upper and lower rail height 76mm, the thickness between the modules is 3mm German imported transparent tape.
Glass assembly: Safety or fire resistant glass with a thickness of 12 mm.
Fire endurance: EI60min
Impact strength: 450Nm
Sound insulation load: 45dB-60dB

  Suggestion: In order to achieve better sound insulation effect, it is best to arrange different thickness of glass on the front and back sides. The area of single glass is not more than 3m2. At the same time, it should consider adding unnecessary cost during transportation.
